ISO Certified High Strength Woven Fiberglass Fabric Woven Glass Fiber
Product Introduction
Woven Fiberglass Fabric is made of high-quality fiberglass material, with a temperature resistance of up to 550℃. It is available in widths of 1000mm-2000mm and thicknesses of 0.2mm-6mm. It also has an excellent flammability rating of UL94V-0. The fiberglass woven fabric is strong and durable, suitable for a variety of applications such as insulation materials, sound insulation materials, fireproof materials, and heat insulation materials. It has the advantages of high temperature resistance, fire protection, low thermal conductivity, corrosion resistance, and excellent electrical insulation properties. Woven Fiberglass Fabric is widely used in the fields of aerospace, automotive, building materials, electronics, and electrical engineering.
| WS3732 |
| Item Model | 3732 Fiberglass Fabric |
| Description | E-glass Industrial Fabric |
| Weave Structure | 1/3 Twill Weave |
| Weight | 430gsm |
| Thickness | 0.43mm |
| Yarn Type | Warp | EC9 68 1*2 |
| Weft | EC9 68 1*2 |
| Thread Count | Warp | 18±1 ends/cm |
| Weft | 12±1 picks/cm |
| Break Strength | Warp | 6000 N/5cm |
| Weft | 4500 N/5cm |
| LOI | < 5% |
| Working Temperature | ≤550℃ |
Product Features
- Product Name: Woven Fiberglass Fabric Cloth
- Flammability: UL94V-0
- Width: 1000mm-2000mm
- Material: Fiberglass
- Tensile Strength: 1000N/50mm
Applications:
Woven fiberglass cloth is a high-quality, durable, and versatile material made from woven fiberglass filaments. Its excellent tensile strength and elongation make it ideal for a wide range of applications. Wingsec Woven Fiberglass Cloth is ISO 9001, NFPA701, and DIN4102 certified. Minimum order quantity is 100 meters. It can be packaged in rolls, cartons, or other packaging, with delivery within 5-14 days after payment. Prices are negotiable, and daily supply capacity can reach up to 10,000 square meters. We offer various weaves, including plain weave, twill weave, and satin weave, to meet different needs.
Much More Related Products
| Fiberglass Cloth Roving |
| Item Name | Thickness (mm) | Weight (g/m2) | Weave | Width Length (cm) | Remarks |
| E7628 | 0.18 | 180 | Plain | 127 | All Size Can be Customized |
| C7628 | 0.2 | 200 | Plain | 100/130/150 |
| CW280 | 0.28 | 280 | Plain | 102 |
| E3732 | 0.38 | 430 | 1/3 Satin | 100/120/150/180/200 |
| C3732 | 0.38 | 430 | 1/3 Twill | 100/120/150/180/200 |
| 2523 | 0.38 | 380 | Plain | 100/120/150/180/200 |
| E666 | 0.6 | 630 | 8H Satin | 100/120/150/180/200 |
| C666 | 0.6 | 630 | 8H Satin | 100/120/150/180/200 |
| E3784 | 0.8 | 850 | 8H Satin | 100/120/150/180/200 |
| C3784 | 0.8 | 850 | 8H Satin | 100/120/150/180/200 |
| E3786 | 1.2 | 850 | 8H Satin | 100/120/150/180/200 |
| C3786a | 1.2 | 1000 | 12H Satin | 100/120/150/180/200 |
| C3786b | 1.2 | 1200 | 12H Satin | 100/120/150/180/200 |
| C3786c | 1.2 | 1300 | 12H Satin | 100/120/150/180/200 |
| E3788 | 1.6 | 1650 | 12H Satin | 100/120/150/180/200 |
| C3788 | 1.6 | 1650 | 12H Satin | 100/120/150/180/200 |
Product Tags:
|
|
High Strength Woven Fiberglass Fabric ISO Certified Woven Glass Cloth Images
|
