Non-Flame Silicone Coated Fiberglass Fabric with S.S Wire Reinforced for Fire Curtain
Description:
White silicone-coated, stainless steel wire-reinforced fiberglass fabric for fire curtains (1000°C high temperature resistance) is a high-performance, high-temperature fireproof fabric. It has a weight of 820 g/m² and is coated with silicone on both sides, enhancing its durability and high-temperature resistance. Furthermore, it is reinforced with 316 stainless steel wire, which increases its tensile strength, flexibility, and mechanical properties.
With a maximum temperature resistance of 1000°C, this fabric is ideal for high-temperature fire curtains, fire barriers, and other applications requiring fire and high-temperature resistance.
In addition to its high-temperature and flame-retardant properties, this fabric is lightweight, flexible, easy to handle, and can be easily molded into desired shapes. In addition to its excellent thermal and chemical stability, this fabric also exhibits strong resistance to tearing, abrasion, and rupture, making it a cost-effective solution for a variety of industrial applications.
Overall, white silicone-coated fiberglass fabric for fire curtains (1000°C reinforced with stainless steel wire) is an excellent choice for industrial applications requiring high-temperature resistance, fire resistance, and excellent mechanical properties.
Product Features
- Block the spread of flames
This material has exceptional fire-resistant properties, effectively blocking the spread of flames, making it one of the best choices for fire curtain system. - S.S. (V4A) wire insided
The stainless steel wire inside fiberglass fabric enhances its tensile strength and temperature resistance. It provides additional structural support, preventing deformation under high heat and mechanical stress, making the fabric more durable and reliable for industrial applications. - Fire resistance 120 min at 1000 ºC
The material provides fire resistance for 120 minutes at 1000ºC (Integrity). When used with a sprinkler system, it can meet fire resistance tests for even longer durations.
Application
- removable insulation pads and jackets
- welding blankets and equipment protection
- fire and heat barriers
- fire retardant curtains, welding curtains
- fabric expansion joints
- lagging, gaskets, and seals
- refineries, power plants, and offshore drilling platforms
Much More Choice
| Product Type | Thickness mm | Weight g/m2 | Weave |
| YD3732-PU1 | 0.43 | 455 | Twill |
| YD3732-PU2 | 0.43 | 470 | Twill |
| YD3784-PU1 | 0.8 | 870 | 8H Satin |
| YD3784-PU2 | 0.8 | 900 | 8H Satin |
| YD-MPT5005-PU1 | 0.5 | 540 | Plain |
| YD-MPT5005-PU2 | 0.5 | 560 | Plain |
| YD-M666 SS-PU1 | 0.65 | 660 | 8H Satin |
| YD-M666 SS-PU2 | 0.65 | 700 | 8H Satin |
| YD-M860SC SS-PU1 | 0.8 | 830 | 8H Satin |
| YD-M860SC SS-PU2 | 0.8 | 870 | 8H Satin |
Fire & Smoke Curtain
RFQ
1. How to get free samples?
A: You can contact our sales staff. We can send you some samples for free. But we do not pay for shipping.
2. Are your products certified?
A: Yes, we have a third party fire inspection report
3. How to package your product?
A: We pack the product in a carton or PVC bag. We can also pack according to customers' requirements.
4. Are you a manufacturer?
A: Yes, we are a Chinese manufacturer. We have advanced looms to provide basic cloth
